STRUCTURAL CHARACTERISTICS
Cast iron pump body
stainless steel pump body cover.
Stainless steel mechanical seal(grahite to ceramic)
brass impeller with centrifugal radial flow type
stainless iron or 45# steel shaft
rotection IP44
with thermal overload in single phase motor

OERATING LIMITS
Suction lift up to 8 m
fluid temerature up to 60℃
maximum ambient temperature 40℃

PUMPS INSTALLATION AND ALICATIONS
These pumps are suitable for handling clean water not containing abrasive to the ump components.They are extremely reliable,simle to use,quiet and virtually maintence-free,finding mny uses in domestic and civil alications,and in articular the automatic distribution of water from small and mediu-sized surge tanks,transferring water,watering garedens,etc.
